Fortress Calypso
44 | Technical product information
Description 3W 4W
Seat width, Master Seat mm (inches)
500 (19.7) 500 (19.7)
Back height (excl. headrest), Master Seat mm (inches)
550 (21.7) 550 (21.7)
Seat height (to platform), Master Seat mm (inches)
432-510
(17-20.1) 432-510 (17-20.1)
Armrest height, Master Seat mm (inches)
150-340
(5.9-13.4) 150-340
(5.9-13.4)
Distance between armrests, Master Seat mm (inches)
500 (19.7) 500 (19.7)
Test data
Test weight 125 kg (19.7 stone)
Description 3W 4W
Turning radius (ISO 7176-5) mm (inches)
1170 (46.1) 1600 (63)
Obstacle height (max. user weight) mm (inches)
76 (3) 76 (3)
Ground clearance (max. user weight) mm (inches)
101 (4) 101 (4)
Operating force
Drive lever operation < 60 N
Resetting the automatic fuse (circuit breaker) < 60 N
Electronic switches < 15 N
Connecting the charger plug < 60 N
Technical specications for wheels
Front wheel diameter (3W) mm (inches) 260 x 85 (10.2 x 3.3)
Front wheel diameter (4W) mm (inches) 260 x 85 (10.2 x 3.3)
Rear wheel diameter mm (inches) 260 x 85 (10.2 x 3.3)
Tyre pressure 4W, front wheel bar (psi) 3.5 (50)
Tyre pressure 4W, rear wheel bar (psi) 3.5 (50)
Tyre pressure 3W, front wheel bar (psi) 3.5 (50)
Tyre pressure 3W, rear wheel bar (psi) 3.5 (50)
Batteries
Maximum dimensions of batteries (lxbxh) mm (inches)
197x168x175
(7.8x6.6x6.9) 197x168x175 86
(7.8x6.6x6.9) Ah 72
Max. battery capacity Ah 60 (C20) 60 (C20)
Maximum permitted charging current Ampère 8 8
* height of steering column, collapsed, excluding seat
** range dependent on user weight, condition of tyres, type of terrain, condition of battery and weather conditions.
7.3 Driving programs
The driving programs for Sunrise Medical products can be found on our Web IQ programming congurator website.
To download driving programs:
• Open your web browser
• Go to http://www.sunmedwebiq.com
• Enter your user name and password. Alternatively follow the instructions on the screen to request a customer login and
password.
• You will be logged on
• Accept the website terms of use
• In the navigation pane on the left, click ‘Sunrise HCM Powerchairs’
• Download the .ZIP le and nd the les that correspond to your product conguration.
For more information about the use of Web IQ, in the navigation pane on the left, click ‘Support Documentation’ and download
the Web IQ Dealer manual (OM-QDELPHI-Web IQ…).
