STIEBEL ELTRON HDB-E 13 AU User Manual

ENGLISH
www.stiebel-eltron.com HDB-E AU | 15
INSTALLATION | ENVIRONMENT AND RECYCLING
Specication
16.7 Data table
HDB-E 13 AU HDB-E 18 AU HDB-E 27 AU
234988 234989 234990
Electrical details
Rated voltage V 380 400 415 380 400 415 380 400 415
Rated output kW 12,2 13,5 14,5 16,2 18 19,4 23,5 26 28
Rated current A 18,5 19,5 20,2 24,7 26 27 35,6 37,7 38,9
Fuse A 20 20 20 25 25 32 35 40 40
Phases 3/PE 3/PE 3/PE
Frequency Hz 50/60 50/60 50/- 50/60 50/60 50/- 50/60 50/60 50/-
Max. mains impedance at 50Hz Ω 0,379 0,360 0,347 0,254 0,241 0,232
Specific resistance ρ
15
≥ (at ϑcold ≤35 °C) Ω cm ≥1100 ≥1100 ≥1200 ≥1100 ≥1100 ≥1200 ≥1100 ≥1100 ≥1200
Specific conductivity σ
15
≤ (at ϑcold ≤35°C) μS/cm ≤910 ≤910 ≤830 ≤910 ≤910 ≤830 ≤910 ≤910 ≤830
Connections
Water connection G 1/2 A G 1/2 A G 1/2 A
Application limits
Max. permissible pressure MPa 1 1 1
Values
Max. permissible inlet temperature °C 35 35 35
ON l/min >2,3 >2,3 >2,3
Flow rate for pressure drop l/min 5,2 5,2 7,7
Pressure drop at flow rate MPa 0,08 (0,06 without DMB) 0,08(0,06 without DMB) 0,16(0,12 without DMB)
Flow rate limit at l/min 7,5 7,5 8,5
DHW delivery l/min 6,9 9,2 13,8
Δϑ at DHW delivery K 28 28 28
Hydraulic data
Rated capacity l 0,4 0,4 0,4
Versions
Temperature adjustment °C 50 50 50
Protection class 1 1 1
Insulation block Plastic Plastic Plastic
Heating system heat generator Bare wire Bare wire Bare wire
Cap and back panel Plastic Plastic Plastic
Colour white white white
IP-Rating IP25 IP25 IP25
Dimensions
Height mm 470 470 470
Width mm 225 225 225
Depth mm 117 117 117
Weights
Weight kg 3,6 3,6 3,6
Guarantee
The guarantee conditions of our German companies do not
apply to appliances acquired outside of Germany. In countries
where our subsidiaries sell our products a guarantee can only
be issued by those subsidiaries. Such guarantee is only grant-
ed if the subsidiary has issued its own terms of guarantee. No
other guarantee will be granted.
We shall not provide any guarantee for appliances acquired in
countries where we have no subsidiary to sell our products.
This will not aect warranties issued by any importers.
Environment and recycling
We would ask you to help protect the environment.
After use,
dispose of the various materials in accordance with national
regulations.
ENVIRONMENT AND RECYCLING
