OPERATION
Menu structure
www.stiebel-eltron.com WPF | WPF cool | 11
Level 3
Cooling
ACTUAL TEMPERATURE FAN °C
SET TEMPERATURE FAN °C
ACTUAL TEMPERATURE AREA °C
SET TEMPERATURE AREA °C
Electric booster heater
DUAL MODE TEMP HEATING
Heating dual mode point
°C
APPLICATION LIMIT HEATING
Heating application limit
°C
DUAL MODE TEMP DHW
DHW dual mode point
°C
APPLICATION LIMIT DHW
DHW application limit
°C
Source
SOURCE TEMPERATURE °C
SOURCE TEMPERATURE MIN °C
SOURCE PRESSURE bar
5.1.2 INFO HEAT PUMP
Hinweis
The power consumption is calculated on the basis of re-
frigerant circuit pressure. This calculation is inappropri-
ate for billing purposes. Together with the amount of heat
it is used for a rough energy statement.
Level 3
Process data
HOT GAS TEMPERATURE
Compressor outlet temperature
°C
HIGH PRESSURE bar
LOW PRESSURE bar
Amount of heat
COMPRESSOR HEATING DAY
Compressor heat amount in heating mode since 00:00 h today in
kWh.
kWh
COMPRESSOR HEATING TOTAL
Total amount of compressor heat generated in heating mode in
MWh.
MWh
COMPRESSOR DHW DAY
Compressor heat amount in DHW mode since 00:00 h today in kWh.
kWh
COMPRESSOR DHW TOTAL
Total amount of compressor heat generated in DHW mode in MWh.
MWh
BH HEATING TOTAL
Total amount of heat generated by the electric emergency/booster
heater in heating mode in MWh.
MWh
BH DHW TOTAL
Total amount of heat generated by the electric emergency/booster
heater in DHW mode in MWh.
MWh
POWER CONSUMPTION
COMPRESSOR HEATING DAY
Electrical output of compressor in heating mode since 0:00 h today.
kWh
COMPRESSOR HEATING TOTAL
Total electrical output of compressor in heating mode.
MWh
COMPRESSOR DHW DAY
Electrical output of compressor in DHW mode since 0:00 h today.
kWh
COMPRESSOR DHW TOTAL
Total electrical output of compressor in DHW mode
MWh
Runtimes in hours
HEATING COMPRESSOR 1
Runtime of compressor 1 in heating mode.
Hours
DHW COMPRESSOR 1
Runtime of compressor 1 in DHW mode.
Hours
COOLING COMPRESSOR 1
Runtime of compressor 1 in cooling mode.
Hours
NHZ 1
Runtime of electric emergency/booster heater in booster stage 1.
Hours
NHZ 2
Runtime of electric emergency/booster heater in booster stage 2.
Hours
NHZ 1/2
Runtime of electric emergency/booster heater in booster stages 1
and 2.
Hours
STARTS
COMPRESSOR
