STIEBEL ELTRON WPF 13 User Manual

www.stiebel-eltron.com WPF | WPF cool | 75
INSTALLATION
Specication
WPF 04 cool WPF 05 cool WPF 07 cool WPF 10 cool WPF 13 cool WPF 16 cool
Versions
Refrigerant R410 A R410 A R410 A R410 A R410 A R410 A
Refrigerant charge kg 1.05 1.40 1.72 2.03 2.30 2.35
Compressor oil Emkarate RL
32 3MAF
Emkarate RL
32 3MAF
Emkarate RL
32 3MAF
Emkarate RL
32 3MAF
Emkarate RL
32 3MAF
Emkarate RL
32 3MAF
Condenser material 1.4401/Cu 1.4401/Cu 1.4401/Cu 1.4401/Cu 1.4401/Cu 1.4401/Cu
Evaporator material 1.4401/Cu 1.4401/Cu 1.4401/Cu 1.4401/Cu 1.4401/Cu 1.4401/Cu
Circulation pump type, heating side Yonos PARA
25/7.0
Yonos PARA
25/7.0
Yonos PARA
25/7.0
Yonos PARA
25/7.5
Yonos PARA
25/7.5
Stratos PARA
25/1-8
Circulation pump type, heat source side Yonos PARA
RS 25/7.5
PWM GT
Yonos PARA
RS 25/7.5
PWM GT
Stratos PARA
25/1-8
Stratos PARA
25/1-8
Stratos PARA
25/1-8
Stratos PARA
25/1-12
IP rating IP20 IP20 IP20 IP20 IP20 IP20
Dimensions
Height mm 1319 1319 1319 1319 1319 1319
Width mm 598 598 598 598 598 598
Depth mm 658 658 658 658 658 658
Weights
Weight kg 158 160 165 177 182 192
Connections
DHW flow/return push-fit connection 28 mm 28 mm 28 mm 28 mm 28 mm 28 mm
Heat source flow/return push-fit connection 28 mm 28 mm 28 mm 28 mm 28 mm 28 mm
Heating flow/return push-fit connection 28 mm 28 mm 28 mm 28 mm 28 mm 28 mm
Values
Available external pressure differential, heating system hPa 690 525 465 440 180 300
Available external pressure differential, heat source hPa 610 630 755 660 395 920
Nominal heating flow rate at A2/W35, B0/W35 and 7 K m³/h 0.58 0.71 0.92 1.26 1.64 2.09
Min heating flow rate m³/h 0.47 0.57 0.75 1.00 1.29 1.62
Heating flow rate (EN 14511) at A7/W35, B0/W35 and 5 K m³/h 0.78 1.04 1.28 1.78 2.28 2.91
Flow rate, heat source side m³/h 1.15 1.41 1.82 2.61 3.22 4.20
Internal volume, heating side l 6.4 7.1 7.1 7.7 8.3 8.3
Internal volume, heat source side l 10.3 10.9 11.7 12.2 13.0 13.5
Expansion vessel pre-charge pressure, heating side MPa 0.15 0.15 0.15 0.15 0.15 0.15
Expansion vessel volume, heating side l 24 24 24 24 24 24
Expansion vessel pre-charge pressure, heat source side MPa 0.05 0.05 0.05 0.05 0.05 0.05
Expansion vessel volume, heat source side l 24 24 24 24 24 24
Conversion: 1 m
3
/h = 16.67 l/min
