Stiga 991313 - CONTROLS AND FEATURES; Key Controls; Operational Levers & Systems

EN - 13
1. Fuel Tank and Cap
2. Fuel Level Window
3. Oil Filter
4. Oil Drain
5. Engine Oil Dipstick
6. Air Filter
7. Ignition Key
8. Choke Control Knob
9. Throttle Control Lever
10. Power Take-off (PTO) Knob
11. Hour Meter
12. Height-of-Cut Adjustment System
13. Transport Lock Release Lever
14. Deck Lift Pedal
15. Seat Adjustment Lever
16. Parking Brake Lever
17. Belt Cover (3)
18. Steering Lever (2)
19. Discharge Chute
20. Anti-Scalp Wheel (6)
21. Transaxle Bypass Lever (2)
22. Battery (Under Seat)
23. Fuse Box
24. Hydraulic Oil Expansion Tank (2)
CONTROLS AND FEATURES
