EN - 5
On position.
Start position.
•
Activated.
Deactivated.
The power take-off must never be activated
when the front attachment is in the work/maintenance position.
This would damage the belt transmission.
•
The levers allow the machine to be moved manually (push
or pull), without starting the engine.
Transmission engaged (8:A2).
Transmission released (8:A1). the
machine can be moved by hand.
The release lever must never be between the
outer and inner position. This condition will cause overheating
and damage the transmission.
5.
5.1.
•
The machine is supplied without engine oil
or fuel.
Check if there is fuel and check the oil level before using the
machine. For methods and precautions on refuelling and
topping up oil, follow the instructions in the engine handbook.
•
See gure 9.
The seat is reclining and can be locked in
an upward reclined position using the stop
(Fig. 9.B).
To adjust the seat:
1. Loosen the screws (9:A).
2. Move the seat to the required position: can be moved
forwards and backwards
3. Tighten the screws (9:A).
•
Unscrew the adjustment handle from the steering wheel to
lift or lower it into the desired position. Tighten.
•
Manual adjustment - mod. V 302 (6:H):
Electric adjustment - mod. V 302 S (7:C)
The switch allows continuous adjustment of the
cutting height.
The cutting means assembly is connected to the socket
(7:G).
• Tyre pressure
For tyre pressure see "0 TABLE OF TECHNICAL DATA".
•
NOTE This machine can be used to mow lawns in a number
of different ways; before starting, prepare the machine based on
how the lawn is to be mowed.
5.2.
•
Result
Battery. No damage to the casing,
cover or terminals.
Fuel lines and
connections.
No leaks.
Electrical cables. All insulation intact.
No mechanical damage.
Oil lines. No leaks.
No damage.
Operate the machine
with a forwards/reverse
movement and release
the drive pedal.
The machine slows
down and stops.
Test driving. No abnormal vibrations.
No abnormal sound.
Safety devices. They operate as described
in the next paragraph.
•
Status Action Result
Driver not seated.
Hand brake
engaged
Try starting the
engine.
The engine
does not start.
Driver seated.
Hand brake
released
Try starting the
engine.
The engine
does not start.
Driver seated.
Hand brake
engaged
The Power take-
o is activated.
Try starting the
engine.
The engine
does not start.
Driver seated.
Hand brake
engaged The
Power take-o is
deactivated.
Try starting the
engine.
The engine
starts.
Engine running. The driver stands
up from the seat.
The engine
stops.
Engine running.
Cutting means
activated.
Set the mechan-
ical attachment
lifting pedal to the
transport position.
The cutting
means stop.
