STIHL 009, 010, 011
3
8. Fuel
S
ystem 43
8.1 Construction and
Operation of Carburetor 43
8.1.1 Operation of Fuel Pump 43
8.1.2 Operation of Carburetor 43
8.2 Troubleshooting Chart 45
8.3 Leakage Test
(Pressure Test)
on Carburetor 47
8.4 Disassembly of
Carburetor 47
8.5 Repair of Carburetor 48
8.6 Carburetor Adjustment 50
8.6.1 Notes for Fine Adjust-
ment of Carburetor 50
8.7 Fuel Line 51
8.8 Tank Vent 51
8.9 Air Filter and
Choke Valve 52
