STIHL 009, 010, 011 6
1.5 Cutting Attachment Guide bars: STIHL Standard guide bars
without stellite-tipped nose
STIHL Duromatic guide bars
with stellite-tipped nose
STIHL Rollomatic guide bars
with sprocket nose
All types with corrosion-resistant
finish and induction hardened rails
Bar lengths: Duromatic 30 and 35 cm (12 and 14 in)
Rollomatic 30, 35 and 40 cm
(12, 14 and 16 in)
Chain: 9.32 mm (3/8")-Oilomatic-Picco
Chain sprocket: 6-tooth for 3/8" Picco pitch
Chain speed: 13 m/s (42.6 ft/sec) at 7000 r.p.m.
Chain lubrication: Speed-controlled oil pump with
Diaphragm
Oil delivery rate: 6-12 cm
3
/min (0.37-0.74 cu. in/min)
at 7000 r.p.m.
Oil tank capacity: 0.28 L (0.59 US pt)
1.6 Weights Model: 009 010 AV 011 AV
Dry powerhead with
30 cm bar and chain: 4.3 kg 4.6 kg 4.7 kg
(9.51 b) (10.1lb) (10.4Ib)
1.7 Special Accessories STIHL repair kit 009, 010, 011 1120 900 5000
Set of gaskets 009, 010, 011 1120 007 1050
