No. Part Name Part No. Application Rem.
1 Locking strip for piston 0000 893 5903 Blocking crankshaft 1) 2)
2 Locking strip for piston 4221 893 5900 Blocking crankshaft 2) 3)
3 Press sleeve 4112 893 2401 Fitting oil seal
(starter side)
4 Press sleeve 1118 893 2401 Fitting oil seal
(clutch side)
5 Installing sleeve 4112 893 2400 Protecting oil seal
(clutch side)
6 Puller 5910 890 4400 Removing oil seals 4)
7 - Jaws (No. 3.1 + 4) 0000 893 3706
8 Puller 4133 893 0800 Removing flywheel
9 Crimping tool 5910 890 8210 Attaching connectors to
electrical wires
10 Assembly drift 1110 893 4700 Removing and fitting piston pin
Removing and installing
clutch drum 2) 3)
11 Clamping strap 0000 893 2600 Compressing piston rings
12 Wooden assembly block 1108 893 4800 Fitting piston
13 Carburetor and 1106 850 2905 Testing carburetor
crankcase tester for leaks
14 Vacuum pump 0000 850 3501 Testing crankcase for leaks
15 - Nipple 0000 855 9200
16 - Fuel hose 1110 141 8600
17 Sealing plate 0000 855 8106 Sealing exhaust port for
leakage test
18 Test flange 1128 850 4200 For leakage test
19 Setting gauge 1127 890 6400 Setting air gap between ignition
module and flywheel
20 Socket, 13 mm 5910 893 5608 Clutch and flywheel nut,
decompression valve
21 Torque wrench 5910 890 0301 0.5 - 18 Nm 5)
(0.4 - 13.5 lbf.ft)
5910 890 0302 6)
22 Torque wrench 5910 890 0311 6 - 80 Nm 5)
(4.4 - 60 lbf.ft)
5910 890 0312 6)
23 Spline screw socket T27x125 0812 542 2104 IS screws
24 Hook 5910 893 8800 Removing pickup bodies
25 Installing tool 5910 890 2210 Installing hookless snap rings
in piston
26 Press arbor 4119 893 7200 Removing and installing ball bearings
27 Service tool ZS 5910 890 2220 Removing crankshaft
28 - Sleeve (4x) 1123 851 8300 1) 2)
29 - Extension 4116 894 1000 1) 2)
30 - Spline screw 9022 341 1190 1) 2)
31 Puller 4119 890 4600 Removing crankshaft
(clutch side)
13. Special Servicing Tools and Aids
13.1 Special Servicing Tools
FS 120, 200, 300, 350, 400, 450, FR 350, 450 59
