Stihl FS 130 R User Manual

FS 130, FS 130 R
English
30
Toolless filler cap (with folding grip)
Threaded filler cap
Opening the toolless filler cap
N Swing the grip into an upright
position.
N Turn the cap counterclockwise
(approx. 1/4 turn).
N Remove the filler cap.
Refueling
Take care not to spill fuel while fueling,
and do not overfill the tank.
Closing the toolless filler cap
N Position the cap with the grip in an
upright position; the raised
positioning marks must line up.
N Turn cap clockwise as far as it will
go (approx. 1/4 turn).
N Fold the grip down so that it is flush
with the surface.
If the grip is not flush with the surface
and the lug on the clip does not engage
entirely in the recess (arrow), the cap is
not properly closed and the steps
described above must be repeated. See
also the "Toolless cap with grip" section
in the Safety Precautions.
Opening the threaded filler cap
N Turn the cap counterclockwise until
it can be removed from the tank
opening.
N Remove the filler cap.
Refueling
Take care not to spill fuel while fueling
and do not overfill the tank.
002BA418 KN
002BA419 KN
249BA053 KN
249BA054 KN
249BA055 KN
249BA056 KN
002BA447 KN
