Stihl FS 130 Manual

56 Series 4180 Powerhead
Check the flywheel:
Have pole shoes turned blue?
Install new flywheel
Check air gap
and reset if necessary
Check the ignition lead:
– Severe chafing?
– Spark plug boot: Holes/cracks?
– Resistance: spark plug boot to ground: spec.
1.5 – 12 kΩ
– Check resistance of ignition lead
Spec.: < 10 Ω,
If necessary, install new spark plug boot and/or
ignition lead,
if ignition lead is molded to ignition module:
– Install new ignition module
Disconnect short circuit wire
from ignition module
1
3
yes
no
2
Ignition
spark?

Stihl FS 130 Specifications

General

Engine Type	4-MIX
Displacement	36.3 cc
Sound Power Level	109 dB(A)
Weight	5.9 kg
Fuel Capacity	0.53 liters
Cutting Diameter	420 mm
Maximum Recommended Cutting Diameter (with blade)	250 mm
Maximum Recommended Cutting Diameter (with line head)	420 mm
Engine Power	1.4 kW (1.9 bhp)
