Stihl FS 130 Manual

55Series 4180 Powerhead
8.4 Ignition System Troubleshooting
Machine does not run
Slide control in position # or
stop switch
in position "I"?
Check the spark plug:
– Smeared with oil, black?
– Sooted?
– Electrode gap correct?
– Contacts shorted?
Clean, readjust or replace the spark plug
Check the spark plug boot:
– Firmly seated on plug
(leg spring)?
– Leg spring hook in center of ignition lead?
– Boot damaged?
If necessary, install new spark plug boot
and/or leg spring
Test ignition system with ZAT 3
or ZAT 4
(use ZAT 3 as main spark gap
see TI 32.94)
1

Stihl FS 130 Specifications

General

Engine Type	4-MIX
Displacement	36.3 cc
Sound Power Level	109 dB(A)
Weight	5.9 kg
Fuel Capacity	0.53 liters
Cutting Diameter	420 mm
Maximum Recommended Cutting Diameter (with blade)	250 mm
Maximum Recommended Cutting Diameter (with line head)	420 mm
Engine Power	1.4 kW (1.9 bhp)
