Stihl FSA 86 R User Manual

0458-833-8221-A
3
English 3 Main Parts
WARNING
Indicates a hazardous situation that, if not avoided, could
result in death or serious injury.
NOTICE
Indicates a risk of property damage, including damage to the
machine or its individual components.
2.2 Symbols in Text
The following symbol is included to assist you with the use
of the manual:
3.1 Trimmer and Battery
1 Battery Compartment
Holds the battery.
2 Locking Lever
Secures the battery in the battery compartment.
3 Control Handle
Handle for the operator's rear hand.
4 Trigger Switch
Switches the motor on and off.
5 Ergo-Lever
Holds the retaining latch in the unlocked position.
Refers to a designated chapter or sub-chapter in this
instruction manual.
3 Main Parts
1
3
2
#
4
7
6
9
8
5
12
10 11
0000097271_001

Stihl FSA 86 R Specifications

General

Type	String trimmer
Cordless	Yes
Head type	Nylon line
Handle type	D-loop handle
Product color	Black, Orange, White
Uncertainty K	2 m/s²
Sound power level	91 dB
Vibration emission	3.7 m/s²
Sound pressure level	77 dB
Cutting diameter (max)	350 mm
Power source	Battery
Battery voltage	36 V

Weight and Dimensions

Length	1720 mm
Weight	3200 g
