Definitions
1 Cutting Blades
Steel blades for cutting hedges and
shrubs.
2 Blade Drive Gear
Converts rotary movement of angle
drive into reciprocating movement
of cutting blades.
3 Drive Tube
Encloses and protects the drive
shaft between the coupling sleeve
and gearbox.
4Angle Drive
Transmits rotary motion of drive
shaft to the blade drive gear.
5 Sliding Sleeve
Locks and unlocks the cutter bar
adjusting mechanism.
6 Quadrant
Locks the cutter bar in the required
position.
7 Adjusting Lever
Used to set cutter bar to the
required angle.
8 Blade Scabbard
Covers cutting blades when hedge
trimmer is not in use.
9 Sleeve
Locates drive tube in coupling
sleeve.
Cutting Blades
Weight
Users of this machine may only carry out
the maintenance and service work
described in this user manual. All other
repairs must be carried out by a
servicing dealer.
STIHL recommends that you have
servicing and repair work carried out
exclusively by an authorized STIHL
servicing dealer. STIHL dealers are
regularly given the opportunity to attend
training courses and are supplied with
the necessary technical information.
When repairing the machine, only use
replacement parts which have been
approved by STIHL for this power tool or
are technically identical. Only use high-
quality replacement parts in order to
avoid the risk of accidents and damage
to the machine.
STIHL recommends the use of original
STIHL replacement parts.
Original STIHL parts can be identified by
the STIHL part number, the {
logo and the STIHL parts symbol K
(the symbol may appear alone on small
parts).
Specifications
Type: Double-edged
for bidirectional
cutting
Cutting length: 500 mm,
600 mm
Tooth spacing: 34 mm
Tooth height: 22 mm
Sharpening angle: 45° to
horizontal
HL-KM 0° 500 mm: 1.7 kg
HL-KM 145° 500 mm: 2.4 kg
HL-KM 145° 600 mm: 2.6 kg
Maintenance and Repairs
