2.2 Symbols in Text
The following symbol is included to assist you with the use
of the manual:
3.1 HLA 66 Hedge Trimmer and Battery
1Drive Tube
Hedge trimmer shaft.
2 Loop Handle
Handle for the operator's front hand.
3 Front Handle
Handle for the operator's front hand.
4 Cutting Blades
Steel blades for cutting hedges, shrubs and bushes.
Refers to a designated chapter or sub-chapter in this
instruction manual.
3 Main Parts
1
2
10
11
14
5
7
6
4
#
12
13
9
8
17
3
0000097077_001
16
15
#
17
