Stihl HSE 71 Instruction Manual

HSE 61, HSE 71, HSE 81
English
9
N Make a loop (3) in the extension
cord.
N Pass the loop (3) through the
opening (4).
N Slip the loop (3) over the hook (5)
and pull it tight.
N Connect the extension cord plug to
a properly installed wall outlet.
N Make sure you have a secure and
balanced footing.
N Stand upright – hold the power tool
in a relaxed position.
N Make sure the cutting attachment is
not touching the ground or any other
objects.
N Hold the unit with both hands – one
hand on the control handle – one
hand on the loop handle.
N Push the switch lever (1) against
the loop handle and hold it there.
N Push down the trigger switch
lockout (2), depress the trigger
switch (3) and hold them in that
position.
The machine is designed for two-hand
operation, i.e. it will run only when the
operator’s hands are on the switch
lever (1) and trigger switch (3).
To extend reach
N Hold the power tool with both hands
– one hand on the control handle –
one hand on the auxiliary switch at
the rear end of the control handle.
N Operate the auxiliary switch (4) and
hold it in that position.
N Push down the trigger switch
lockout (2), depress the trigger
switch (3) and hold them in that
position.
The machine is designed for two-hand
operation, i.e. it will run only when the
operator’s hands are on the auxiliary
switch (4) and trigger switch (3).
4
3
5
279BA019 KN
Switching On
2
3
1
279BA020 KN
279BA021 KN
2
3
4

Stihl HSE 71 Specifications

General

Blade size	600 mm
Blade type	Double blade
Product color	Grey, Orange, Black
Vibration emission	3.8 m/s²
Engine power	600 W
Power source	Battery
AC input voltage	230 - 240 V
Power cable length	0.31 m

Weight and Dimensions

Depth	1230 mm
Weight	- g
