Stihl KM 110 R User Manual

KM 110 R, KM 130 R
English
21
Conditions for adjustment
N Carry out the standard setting
without disturbing the high speed
screw (H).
N Warm up the engine for about 3
minutes.
N Open the throttle wide.
At high altitude
N Turn the high speed screw (H)
clockwise (leaner), no further than
stop, until there is no further
noticeable increase in engine
speed.
At sea level
N Turn the high speed screw (H)
counterclockwise (richer), no further
than stop, until there is no
noticeable increase in engine
speed.
It is possible that maximum engine
speed may be reached with the standard
setting.
In some countries the muffler is
equipped with a spark arresting screen.
N If the engine is down on power,
check the spark arresting screen in
the muffler.
N Wait for the muffler to cool down.
N Move the slide control to STOP-0.
N Take out the screw (1).
N Take out the screws (2) and remove
the shroud (3).
N Take out the screw (4).
N Lift the spark arresting screen (5)
and pull it out.
N Clean the spark arresting screen. If
the screen is damaged or heavily
carbonized, fit a new one.
N Refit the spark arresting screen.
N Insert the screw and tighten it down
firmly.
N Fit the shroud.
Spark Arresting Screen in
Muffler
249BA059 KN
1
2
3
2
249BA060 KN
