24
english / USA
KM 85, KM 85 R
To reduce the risk of fire and burn
injury, use only spark plugs
authorized by STIHL. Always press
spark plug boot (2) snugly onto
terminal (1) of the proper size.
(Note: If boot has detachable SAE
adapter nut, it must be attached.)
A loose connection between spark
plug boot and ignition wire
connector in the boot may create
arcing that could ignite combustible
fumes and cause a fire.
: Take out the screws (1).
: Remove the cable lug (if fitted).
: Lift the starter cover (2) away from
the tank (3) and pull it out from
under the shroud (4).
: Take out the screw (5).
: Remove the rope rotor very
carefully – the rewind spring is
seated in the rope rotor and may
pop out and uncoil if care is not
taken.
000BA036 TR
1
Replacing the Starter Rope
and Rewind Spring
386BA004 KN
1
1
1
2
3
4
5
392BA014 KN
