45MS 210, MS 230, MS 250
: Tie one of the special knots
shown.
– Pull the rope back into the starter
grip.
– Install the rope rotor – b 8.3.
VA
982RA036
– Tension the rewind spring –
b 8.5.2.
: Pry the nipple of the starter rope
out of the starter grip. Pull out the
starter rope.
VA
208RA052
: Thread new starter rope through
the top of the starter grip.
VA
208RA051
: Thread the other end of the rope,
from outside, through the guide
bush in the fan housing.
– Fit the rope in the rope rotor –
b 8.5.
– Install the rope rotor – b 8.3.
VA
208RA049
– Fit the fan housing – b 8.2.
: Pull out the starter rope until the
nipple (1) locates in the starter
grip.
VA
208RA050
1
8.5.1 Elastostart

Stihl MS 210 Specifications

General

Displacement	35.2 cm³
Bar Length	35 cm
Chain Oil Capacity	0.2 L
Chain Pitch	3/8"
Fuel Capacity	270 ml
