Stihl MS 210 Service Manual

49MS 210, MS 230, MS 250
: Pry the annular buffer out of the
handle housing.
135RA128 VA
: Push the annular buffer into the
handle housing from outside until
its groove (1) engages over the
rib (2).
– Install the handle housing –
b 9.3.
VA
135RA129
2
1
: Take the lower mounting screws
out of the front handle.
VA
135RA130
– Remove lower bumper strip from
the tensioner.
: Ease plugs out of the annular
buffers.
135RA131 VA
: Take out the screws.
: Pull the lower part of the handle
housing out of the front handle.
– Remove the front handle.
Reassemble in the reverse
sequence.
VA
135RA133
– Tighten down screws in annular
buffers to 3.5 Nm (2.6 lbf.ft).
9.2 Front Handle

Stihl MS 210 Specifications

General

Displacement	35.2 cm³
Bar Length	35 cm
Chain Oil Capacity	0.2 L
Chain Pitch	3/8"
Fuel Capacity	270 ml
