Stihl MS 362 C-M Technical Information

Page 9
Technical Information 04.2013
TI_04_2013_30_01_01.fm
4.6 Tightening Torques
All other tightening torques remain as before and
are listed in the STIHL MS 362 service manual.
1
1
5902TI054 KN
3
2
Item Fastener Thread size Component(s) Torque Qty. Remarks
1 Screw M4x20 Control unit / crankcase 35 lbf in
(4.0 Nm)
21)
2 Screw M3x8 Wiring harness / control unit /
clamp
4.0 lbf in
(0.5 Nm)
1
3 Screw M2.5x16 Switch unit / carburetor 9.0 lbf in
(1.0 Nm)
1
Remark
1) Coat micro-encapsulated screws with medium strength Loctite 243 before reinstalling.

Stihl MS 362 C-M Specifications

General

Displacement	59.0 cm³
Power Output	3.5 kW
STIHL Oilomatic saw chain pitch	3/8"
Engine displacement	59.0 cm³
Chain pitch	3/8"
Vibration levels left/right	3.5/3.5 m/s²
Sound power level	117 dB(A)
Sound pressure level	106 dB(A)
Fuel Capacity	0.5 liters
Chain Oil Capacity	0.26 liters
Guide Bar Length	40 cm / 16 in
Fuel tank volume	0.5 liters
Oil tank volume	0.325 L
