Stihl MS 391 Instruction Manual

MS 311, MS 391
English
27
Removing the chain sprocket cover
N Unscrew the nuts and take off the
chain sprocket cover.
N Turn the screw (1)
counterclockwise until the tensioner
slide (2) butts against the left end of
the housing slot.
Disengaging the chain brake.
N Pull the hand guarad towards the
front handle until there is an audible
click – the chain brake is
disengaged.
Fitting the chain
WARNING
Wear work gloves to protect your hands
from the sharp cutters.
N Fit the chain – start at the bar nose.
N Fit the guide bar over the studs (1) –
the cutting edges on the top of the
bar must point to the right.
N Engage the peg of the tensioner
slide in the locating hole (2) –- place
the chain over sprocket (3) at the
same time.
N Turn the tensioning
screw (4)clockwise until there is
very little chain sag on the
underside of the bar – and the drive
link tangs are engaged in the bar
groove.
N Refit the sprocket cover and screw
on the nuts only fingertight.
N Go to chapter on "Tensioning the
Saw Chain"
Mounting the Bar and Chain
143BA034 KN
1
2
001BA185 KN
001BA186 KN
143BA003 KN
3
1
1
2
4
001BA187 KN

Stihl MS 391 Specifications

General

Motor type	2-stroke motor
Chain gauge	1.6 mm
Chain pitch	3/8 \
Automatic oiling	Yes
Oil tank capacity	0.35 L
Fuel tank capacity	0.6 L
Engine displacement	64.1 cm³
Engine power	4.4 hp
Power source	Gasoline

Weight and Dimensions

Weight	6200 g
