0458-716-8621-E
58
English
26 Specifications
– Frequency: 60 Hz
– Charging current: 1.5 A
– Rated power: 75 W
– Insulation: Class II (Double Insulation)
– Permissible ambient temperature range during charging:
41 °F to 104 °F (5 °C to 40 °C)
26.7 Symbols on the Chain Saw, Battery and
Charger
26.8 Engineering Improvements
STIHL's philosophy is to continually improve all of its
products. As a result, engineering changes and
improvements are made from time to time. Therefore, some
changes, modifications and improvements may not be
covered in this manual. If the operating characteristics or the
appearance of your machine differs from those described in
this manual, please contact your STIHL dealer or the STIHL
distributor in your area for assistance.
26.9 FCC 15 Compliance Statement
This device complies with part 15 of the FCC Rules.
Operation is subject to the following two conditions:
– this device may not cause harmful interference.
Symbol Explanation
VVolt
Hz Hertz
A Ampere
Ah Ampere hour
WWatt
Wh Watt hour
AC Alternating current
IP20 Degree of electrical protection
Engage the chain brake
Disengage the chain brake
Chain oil tank
Maximum guide bar length
Direction of saw chain rotation
Turn clockwise to tension the saw chain
Certification/listing mark of CSA
STIHL products must not be disposed of in the
household trash, but only in accordance with local,
state and federal laws and regulations and as
provided in this manual, @ 29.
Direct current
Number of cells and stored energy according to cell
manufacturer's specification. Usable energy will be
less.
The RBRC seal indicates that STIHL has prepaid for
battery recycling
Read the manual
Insulation: Class II (Double Insulation)
Use and store charger only indoors in dry rooms
California Energy Commission. This battery system
complies with the California Energy Commission
efficiency requirements.
Manufacturer Code
):*%
