Stihl RE 120 PLUS User Manual

0458-620-0121-A
16
English 7 Assembling the pressure washer
Attaching the spraying set
► Insert spraying set (1).
Inserting the nozzles and cleaning pin
► Open the flap (1).
► Insert fan-jet nozzle (2) and rotary nozzle (3).
► Insert cleaning pin (4).
7.2 Pulling out and pushing in the handle
7.2.1 Pulling out the handle
► Press the safety catch (1) and pull out the handle (2).
► Release safety catch (1) and pull out handle (2) until it
audibly engages.
7.2.2 Pushing in the handle
► Press the safety catch (1) and push in the handle (2).
► Release safety catch (1) and push in handle (2) until it
audibly engages.
0000-GXX-4611-A0
1
2
0000-GXX-5086-A0
1
4
3
0000-GXX-4619-A0
1
2
2
0000-GXX-4620-A0
1

Stihl RE 120 PLUS Specifications

General

Brand	Stihl
Model	RE 120 PLUS
Category	Pressure Washer
Language	English
