Stihl RE 581 Instruction Manual

RE 521, RE 551 PLUS, RE 581, RE 581 PLUS
English
44
Fill with STIHL scale inhibitor
N Open storage tank cap (1)
N Fill with STIHL scale inhibitor
N Replace cap on storage tank
N Pull back and hold the coupling (1)
N Push the spray lance (2) into the
mount on the spray gun, or pull it out
to remove the spray gun,
respectively
N Release the coupling (1)
Machines without hose reel
Connecting the high-pressure hose
N Push the high-pressure hose (1)
onto the connector of the machine
N Attach union nut (2) and screw it on
and tighten by hand
Disconnect the high-pressure hose
N Unscrew the union nut (2)
N Pull high-pressure hose (1) off of
connector
Machines with hose reel
The high-pressure hose is already
connected.
Disconnect the high-pressure hose
N Unroll high-pressure hose
Fitting, removing spray lance
647BA021 KN
1
2
Fitting, removing high-
pressure hose
1
675BA007 KN
2
