Stihl SG 31 User Manual

SG 31
English
8
Releasing pressure in solution container
N Pull the piston manometer up all the
way – pressure is released – wait
until container is completely
depressurized.
Pressure must be released:
– before filling the container
– after spraying
– to drain and clean the container
– before carrying out maintenance
work
Spray Gun
Unlocking / locking spray gun
N Push locking lever (1) upwards – the
trigger (2) is unlocked and can be
operated.
N Push the locking lever (1)
downwards – the trigger (2) is
locked to reduce the risk of
accidental operation.
Wand Extension
N Loosen the union nut (1).
N Pull the wand extension (2) out to
the required length and line it up –
nozzle orifice facing down.
N Tighten down the union nut (1)
firmly.
6159BA010 KN
1
6159BA024 KN
2
1
2
6159BA011 KN
1
6159BA012 KN
2

Stihl SG 31 Specifications

General

Volume	5 L
Material	-
Product color	Black, Orange, White
Quantity per pack	1 pc(s)

Weight and Dimensions

Weight	1800 g
