SG 51, SG 71
English
8
N Use a screwdriver to pry the pin (1)
out of the backplate.
N Remove the pin (1) and pull out the
ends of the harness straps (2).
N Fit the ends of the harness
straps (2) in the lower position.
N Insert pin (1) and engage it in the
backplate.
Adjusting the Harness Straps
The SG 71 is equipped with a waist/hip
belt.
A Pull the ends of the straps
downward to tighten the harness.
B Lift the tabs of the adjusters to
loosen the straps.
C Close and lock the quick-release
fastener by pushing it together.
D Squeeze the hooks to open the
quick-release fastener.
8014BA008 AS
1
1
2
2
A
B
271BA047 KN
C
D
271BA048 KN

Stihl Sg 71 Specifications

General

Volume	18 L
Material	-
Product color	Black, Orange, White
Quantity per pack	1 pc(s)

Weight and Dimensions

Weight	5000 g
