SG 51, SG 71
English
9
Make yourself familiar with how the
controls function before using your
sprayer for the first time.
Lever
Pressurizing the tank
N Operate the pump lever slowly and
steadily with the gun closed –
several strokes are required to build
up pressure.
Transport position
N Move the pump lever to upright
position until it engages.
Cap
There are three measuring cups in the
cap. They can be used to prepare the
plant protection solution.
1 5 ml (0.2 fl.oz)
2 10 ml (0.3 fl.oz)
3 25 ml (0.8 fl.oz)
Spray Gun
Unlocking / locking spray gun
N Push locking lever (1) upwards – the
trigger (2) is unlocked and can be
operated.
Controls
8014BA014 AS
8014BA023 AS
8014BA019 AS
3
2
1
1
6159BA024 KN
2

Stihl Sg 71 Specifications

General

Volume	18 L
Material	-
Product color	Black, Orange, White
Quantity per pack	1 pc(s)

Weight and Dimensions

Weight	5000 g
