SG 51, SG 71
English
15
1 Backplate
2 Harness
3 Hose
4 Filter
5 Spray gun
6 Spray wand
7 Spinner insert
8 Hollow cone nozzle
9 Container cap
10 Gasket
11 Strainer
12 Solution container
13 Lever
14 Handle
15 Pump barrel
16 Piston cup seal
17 Retaining pin
# Serial number
Main Parts
8014BA036 AS8014BA033 AS
1
2
14
15
5
6
4
12
13
3
9
10
11
16
17
#
8
7
