7SR 430, SR 450
Fastener Thread size For component Torque Remarks
Nm
M 14x1.25 Spark plug 25.0
Screw M 5x20 Ignition module/engine pan 6.0 1)
Screw M 5x20 Spacer flange/cylinder 6.0 3)
Remarks:
1) Micro-encapsulated with washer
2) Anti-friction coating
3) Binding head screw with anti-friction coating
4) Degrease joint and mount oil-free
5) Seal components with Dirko HT red sealant
Use the following procedure when refitting a DG or P screw in an existing thread:
Place the screw in the hole and rotate it counterclockwise until it drops down slightly.
Tighten the screw clockwise to the specified torque.
Coat micro-encapsulated screws with medium-strength threadlocking adhesive before re-installing.
This procedure ensures that the screw engages properly in the existing thread and does not form a new thread
and weaken the assembly.
Power screwdriver setting for polymer: DG and P screws max. 500 rpm
Do not use an impact wrench for releasing or tightening screws.
Do not mix up screws with and without binding heads.
