(7) With load rack, mandatory for -SF
(8) Value with platform lowered
(9) The fork thickness value indicated is for
use with GITTER-BOX. A carriage with thick-
ness s = 71 mm is also available
(10) Thickness values with forks fully lowered
m
2
= 15 mm
(11) Values with fender
(12) Value with straddles lowered +17 mm
(13) Value with straddles lowered +42 mm
(14) Value with straddles lowered +78 mm
(15) ±5%
(16) Speed in pedestrian mode - Speed when
standing without side protection - Speed when
standing with side protection
(16) On slopes with gentle start and forks
raised (geometric limit with start of slope at =
-9.2%)
(17) Value with Tele mast h3 = 4644 mm
(18) Rounded edge on the side with forks low-
ered (geometric limit on slope =9.2%)
(19) In brackets: maximum surmountable gra-
dient with capacity of 2000 kg on the fork side,
with the initial lift option.
Datasheet (VDI) EXV-SF 14 / EXV-SF 16 and EXV-SF 14i / EXV-SF 16i
CHARACTERISTICS EXV-SF 14 / EXV-SF 16 EXV-SF 14i / EXV-SF 16i
1.3
Power unit: elec-
tric, diesel, petrol,
LPG
Electric Electric
1.4
Drive type: man-
ual, pedestrian,
stand-on, seated,
order picker
Pedestrian/Standing Pedestrian/Standing
1.5 Load capacity
Q
(kg)
1400//1600 1400 (2000)//1600 (2000)
(1)
1.6
Load centre of
gravity
c
(mm)
600 600
Technical data
6
Datasheets
164 45758043484 EN - 11/2021 - 08
