Still EXV 16 - Battery Specifications and Lubricants

1.8
Load distance,
centre of drive
axle to fork
x
(mm)
724
(2)
724
(2)
/646
(2) (3)
1.9 Wheelbase
y
(mm)
1311
(4)
1311
(4)
/1233
(3) (4)
WEIGHT EXV-SF 14 / EXV-SF 16 EXV-SF 14i / EXV-SF 16i
2.1
Service weight (with bat-
tery)
kg 1258 1229
2.2
Axle load with load, drive
side/load side
kg 1040/1619//1059/1800 971/1658//979/1850
2.3
Axle load without load,
drive side/load side
kg 955/304 962/268
WHEELS EXV-SF 14 / EXV-SF 16 EXV-SF 14i / EXV-SF 16i
3.1 Tyres Polyurethane Polyurethane
3.2 Drive wheel sizes mm Ø 230 x L90 Ø 230 x L90
3.3 Wheel sizes, load side mm Ø 85 x L85 (Ø 85 x L60)
(5)
Ø 85 x L85 (Ø 85 x L60)
(5)
3.4 Stabiliser wheels (sizes) mm 2x Ø 150 x L50 2x Ø 150 x L50
3.5
Wheels number, drive side/
load side (x = drive wheel)
1x + 2/2 (1x + 1/4)
(5)
1x + 2/2 (1x + 1/4)
(5)
3.6
Track width, drive side
b10
(mm)
534 534
3.7
Track width, load side
b11
(mm)
380 380
DIMENSIONS EXV-SF 14 / EXV-SF 16 EXV-SF 14i / EXV-SF 16i
4.2 Height of mast, lowered
h1 (
mm)
1915
(6)
1915
(6)
4.3 Free lift
h2 (
mm)
150
(6)
150
(6)
4.4 Lifting
h3 (
mm)
2844
(6)
2844
(6)
4.5 Height of mast, extended
h4 (
mm)
3364
(6)
3364
(6)
4.6 Initial lift
h5
(mm)
/ 110
4.9
Height of tiller arm in driv-
ing position, min/max
h14 (
mm)
1175/1380 1175/1380
4.1
5
Fork height, lowered
h13
(mm)
86 86
4.1
9
Overall length without load
l1
(mm)
1993
(2) (4)
/2401
(2) (4) (7)
1993
(2) (4)
/2401
(2) (4) (7)
Technical data
6
Datasheets
16545758043484 EN - 11/2021 - 08
