4 Operation
Replacing and transporting the bat
tery
1
6321_003-016
Emergency off when moving the battery
When working with the hydraulic battery
carrier, it may not be possible to reach the
emergency off switch. In an emergency,
disconnect the battery male connector (1).
CAUTION
Potential for damage to the battery male connector!
If the battery male connector is connected while
the key switch is on (under load), a jump spark will
be produced. This jump spark can damage the
contacts and considerably shorten the service life
of the contacts.
– Do not connect the battery male connector with
the key switch switched on.
– Make sure that the key switch is switched off
before connecting the battery male connector.
6321_003-074
Extending the battery hydraulically
– Apply the parking brake.
346
171533 EN - 02/2019 - 19
