Still RX70-50 - Joystick 4 Plus

Joystick 4Plus
1
2
3
4
5
9
8
7
6
6210_003-087
Horizontal rocker button for "3rd hydraulic
function", tilt the lift mast
Pictograms for the basic hydraulic functions
Pictograms for the 5th hydraulic function and
the clamp locking mechanism (variant)
Pictograms for the 3rd & 4th hydraulic func-
tions
1
2
3
4
LED for clamp locking mechanism (variant)
Slider for the "4th hydraulic function", e.g.
reach frame forwards/backwards
Vertical rocker button for the "drive direction"
Shift key "F"
Signal horn button
5
6
7
8
9
Overviews
3
Operating devices and display elements
