Stille imagiQ2
TM
user manual Technical
n
Technical
Specification
Dimensions
Outside dimensions
n Length 234 cm/92 in
n Width 77,2cm /30,3 in
n Height 71 cm-109 cm / 28”-43”
Table top
n Length 230 cm /90,5 in (256,8 cm / 101 in
including head section)
n Width 55 cm / 21,6 in
(excluding accessory rails)
n Height 71 -109 cm (centre of the table top)
Panning lengthways 90 cm / 35,4”
Panning sideways 25 cm / 9,9 ”
Longitudinal tilt ± 25 °
(± 20 ° on 300 kg/
661 Lbs version)
Lateral tilt ± 15 °
Head section adjustment ± 35 °
Maximum patient weight 225 kg / 300 kg
496 Lbs / 661 Lbs
Weight of table approx 265 kg
Ground clerance 15mm
Technical specification
Electrical system
Mains voltage 100 - 230 V AC,
50 / 60 Hz
Rated power Max 510 VA
Fuse rating T6,3 H, 250V SB
Input current Max 5.1A
Output power 400W
Enclosure IP 24
Classification type B
Electric safety Class 1
Internal fuses 1pcs 30A 250 VAC Slow
1pcs 30A 250 VAC Slow
1pcs 10A 440 VAC Slow
1pcs 2A 440 VAC Slow
Leakage current
The imagiQ2™ complies with the leakage current
requirements according to IEC 60601-2-46, when
connected to mains
Duty cycle 100%
Battery type 24 V DC
Battery recycling Follow the environmental
authority instructions
carefully.
Hydraulic system
Max system pressure 190 bar
Oil volume approx. 1,5L
Max. flow of pump 0.9 L/min
Oil grade Castrol Hyspin/AWH-M32
or equivalent
Electrical standards applied
IEC 60601-1:2005, third edition, Medical electrical equipment – Part 1: General Requirements for basic safety
and essential performance.
IEC 60601-2-46:2010, second edition, Medical electrical equipment - Part 2-46: Particular requirements for
the basic safety and essential performance of operating tables.
IEC 60601-1-2:2007 third edition, Medical electrical equipment - Part 1-2: General requirements for basic
safety and essential performance - Collateral standard: Electromagnetic compatibility - Requirements and tests.
UL 60601-1 Issued: 2003/04/17 Ed: 1 Rev: 2006/04/26 Standard for Safety Medical Electrical Equipment,
Part 1: General Requirements for Safety
CAN/CSA C22.2 No. 601.1-M90 Issue:1990/01/01 Medical Electrical Equipment - Part 1:
General Requirements for Safety General Instruction No 1; Supplement 1; 1994; Amendment 2 -February
1998; Update No. 2 - General Instruction No.2: 2003/11/01 - (R2005).
Applied part
The mattress is considered to be the applied part
