Explanations of the symbols found in the manual:
Connection for foot control.
Secure
Release
Push
Insertion direction (part)
Adjustable in shown directions
Adjustable in shown directions
NOTE On the equipment
Follow instructions for use
Read accompanying documents
Serial number lable
Fuse rating
Risk for pinch / squeeze injury
Risk for electrical shock
Max safe work load
1779-2LA009-01
1779-2LA010-01
STILLE AB (publ)
Ekbacken 11
SE-644 30 Torshälla
Sweden
225/300 kg
1779-2LA000
imagiQ 2 EU 230V
170013001
530-1700
100-230V
50/60Hz
Max 510 VA
1779-2LA006-02
T 6.3A H 250V
250V
SB
1779-2LA011-01
225 Kg / 496 lb
MAX.
12,2 kg / 26,90 lb
MAX.
1779-2LA012-01
