stimulation level must be set to produce a gentle
muscular contraction.
Mode Burst C – 0.75 second Burst sequence = 0.25s on,
0.5s off. Both Pulse Rate and Pulse Width are adjustable.
Default values are PR=100Hz and PW=150μs. The
stimulation level must be set to produce a gentle
muscular contraction.
EMS:
Intensity 0-130mA to peak at 500ohm load
Frequency 1-110 Hz
Pulse width Positive phase: 50-400μs, in steps of
50μs
Waveform Symmetrical Bi-Phasic rectangular,
Alternated Bi-Phasic rectangular
Ramp up time 0-5s in steps of 1s
Ramp down time 0-5s in steps of 1s
On time 1-60s in steps of 1s
Off time 0-60s in steps of 1s
Treatment timer Continuous, 10, 20, 30, 45, 60, 90min
Program 30-33 (manual) – When using ALTERNATING
Frequency, ensure that the “Ramp up Time”, “On Time”,
and “Ramp down Time” equals “Off Time”.
Ramp Up + On Time + Ramp Down = Off Time
The will appear on your screen if this formula is not
followed in EMS manual mode.
- 20 -
