STINAR PS-813B/E - Specifications and Capabilities

Passenger Stairway PS-813B/E Boeing | 19
SECTION 1 - PROCEDURES, SPECS & CAPABILITIES
1.3 SPECIFICATIONS
AND CAPABILITIES
1.3.1 | General Specifications
DIMENSIONS
Overall Length (less tow bar) 297 in. (7544 mm)
Overall Width 99 in. (2515 mm)
Overall Height (stairway not collapsed) 146 in. (3708 mm)
Maximum Platform Height 228 in. (5790 mm)
Minimum Platform Height 96 in. (2440 mm)
Tow Bar Length 86.25 in. (2191 mm)
Wheelbase 147 in. (3734 mm)
Platform Dimensions
Length 84 in. (2135 mm)
Width 72 in. (1830 mm)
Step Dimensions
Width 48 in. (1220 mm)
Depth 12 in. (305 mm)
Rise 7.5 in. (190 mm)
Railing Height 35 in. (890 mm)
1.3.2 | Capacities
Hydraulic Reservoir 10 U.S. gal. (38 liter)
Caster (ea.) 3700 lb. (1678 kg)
Wheels and Tires
Tires
4:00 x 8 in. soft solid
rubber
Rims 8 in. x 3.75
1.3.3 | Engine Specifications
Manufacturer Honda
Model/Serial No. GX240/GCBJT1218977
Type
4-stroke, OHV, single
cylinder, air-cooled,
gasoline-fueled electric
start
Bore 3.0 in.
Stroke 2.3 in.
Displacement 16.5 cu. in.
Horsepower (bhp), Max 7.9 @ 3600 RPM
