FIGURE 4.3.1 | PASSENGER STAIRWAY, MODEL PS-813B/E - TABLE
FIG ITEM # MFG PART # DESCRIPTION
VENDOR
CODE
QTY
4.3.1- 0 PS-813B/E Passenger Stairway, per 026281-100 Rev A V32526 1
1 026273-100 Rev E Cart Chassis Assembly. See Figure 4.3.2 V32526 1
2 021221-100 Rev A Upper Stairs and Platform. See Figure 4.3.3 V32526 1
3
021527 Rev B
021528 Rev B
Side Panel, Upper Stairs Drivers Side
Side Panel, Upper Stairs Passenger Side
V32526 1
4 1000263 Railing Assy Upper (Short) V32526 2
5 1000265 Railing Assy Upper (Long) V32526 2
6
1000259
1000261
Elephant Ear Assy Dr Side
Elephant Ear Assy Psngr Side
V32526 1
EA SIDE
7 020215-210 Rev D Lower Stair Assembly. See Figure 4.3.4 V32526 2
8 026121 Rev F Stairway Ratchet Assembly. See Figure 4.3.5 V32526 1
9 204497 Stairway Hydraulic Cylinder V32526 1
10 026113 Rev R A-frame Assembly. See Figure 4.3.6 V32526 1
11 N/A Not used V32526 1
12 204074 Cylinder, Stabilizer V32526
13 026119 Rev D Stabilizer Pad V32526 1
14 026278-100 Rev A Hydraulic System. See Figure 4.3.7 V32526 1
15 210033 Hydraulic Tank Kit 15 gal V32526 1
16 207005 Hand Pump V32526 1
17 201097 Directional Valve V32526 1
18 718014 Gasoline Engine V32526 1
19 203159 Hydraulic Pump V32526 1
20 203160 Pump Mount and Coupler kit V32526 1
21 - - - -
4.3.122 026165-100 Rev C Electrical System. See Figure 4.3.10 V32526 1
23 409085 Battery Charger V32526 1
24 409015 Battery, 6 V Marine V32526 2
25 B-3412-1 Rev A Primary Control Station. See Figure 10 V32526 2
26 405277 Stairway Light V32526 12
27 405294 A-frame Light V32526 1
28 1000298 Battery Box V32526 3
29 930002 Hold-Down Strap V32526 3
