Passenger Stairway PS-813B/E Boeing | 59
FIG ITEM # MFG PART # DESCRIPTION
VENDOR
CODE
QTY
4.3.4-0 020215 210 Rev D Lower Stairs Assembly V32526 1
1 021861 Top Step, 48 in. width V32526 1
2 021862 Stair Step, 48 in. width V32526 13
3 021863 Bottom Step, 48 in. width V32526 1
4 1000265 Railing Assy Upper (Long) V32526 2
5 026121 Rev F Stairs Ratchet Assembly. See Figure 4.3.5. V32526 1
6 503065 Guide, Plastic Strip, 1” x 4” x 8 ft. long V32526 2
7 508013 Rev F Roller V32526 2
8 508023 Rev E Shaft V32526 2
9 021888 Upper Stairs Panel Roller Assembly V32526 2
10 508025 Rev E Roller V32526 1
10 021475 Rev A Bumper, 72” long V32526 1
FIGURE 4.3.4 | LOWER STAIRS ASSEMBLY - TABLE
