FIG ITEM # MFG PART # DESCRIPTION
VENDOR
CODE
QTY
4.3.5-0 026121 Rev F Stairway Ratchet Assembly V32526 1
1 022055 Rev A Bracket, Welded to lower stairway. V32526 2
2 022190 Angle, Welded to Item 1. V32526 1
3 508451 Rev A Shaft, 1” dia x 58” length V32526 1
4 509097 Rev C Ratchet Dog V32526 2
5 026166 Rev B Handle, Ratchet Release V32526 1
6 906002 Rev A Set Collar, 1 in. V32526 2
FIGURE 4.3.5 | STAIRWAY RATCHET ASSEMBLY - TABLE
