Firmware description UM1619
30/56 DocID024383 Rev 1
The setup folder contains also the Firmware - Bootloader folder, where inside there is the
bootloader firmware; and the folder Firmware - Sniffer which contains the sniffer workspace
to download in a PLM module useful if the data sniffing feature of the interface is used. In
this case the PLM module will work only as a sniffer.
6.4 Firmware description
The structure of the workspace is divided in different sections as shown in the Figure 24.
The user program must be developed in the user.c and user.h files.
Figure 24. Workspace structure
^LJƐƚĞŵĨŝůĞƐ
W>DĚƌŝǀĞƌ
ƉƉůŝĐĂƚŝŽŶŶŐŝŶĞ
hƐĞƌůĂLJĞƌ
