DocID024383 Rev 1 41/56
UM1619 Firmware description
2) Set module parameters: data link stack parameters
uint8_t *buffer;
buffer[0] = 62;
buffer[1] = APP_SERVICE_FRAME;
buffer[2,3] = target_module.group;
buffer[4,5,6,7] = target_module.address;
buffer[8] = SERVICE_PARAM_SET;
buffer[9] = PROG_GRP_LL_STACK_PARAM;
/* STACK PARAMETERS */
buffer[10,11] = PLM_MIN_SLOT; // Minimum backoff time
buffer[12,13] = PLM_MAX_SLOT; // Maximum backoff time
buffer[14,15] = PLM_NTW_P_GLOBAL_TX_TO; // Timeout for global tx
buffer[16,17,18,19] = PLM_NTW_P_BC_GLOBAL_TX_TO; // Timeout for broadcast frame retransmission
buffer[20,21] = PLM_NTW_P_ACTIVITY_TO; // Timeout for network
buffer[22,23] = PLM_NTW_P_WATCHDOG_TO; // Watchdog timeout
buffer[24,25,26,27] = PLM_NTW_P_DATATRANSFER_TO; // Timeout for completing a transfer from
source to target
buffer[28,29] = PLM_NTW_P_BANDINUSE_TO; // Timeout for the band in use signal
buffer[30,31,32,33] = PLM_NTW_P_FRAME_TX_TO; // Timeout for sending a frame through SPI
buffer[34,35,36,37] = PLM_NTW_P_BCAST_TX_TO; // Timeout for repeat a broadcast frame
buffer[38,39,40,41] = PLM_NTW_P_ACK_RX_TO; // Timeout for receiving an ACK frame
buffer[42,43,44,45] = PLM_NTW_P_bACK_RX_TO; // Timeout for receiving a bACK frame
buffer[46,47,48,49] = PLM_NTW_P_FRM_RX_TO; // Timeout for frame receptions
buffer[50,51,52,53] = PLM_NTW_P_NDX_TO; // Minimum delay before any
buffer[54,55] = PLM_LL_MAX_ATTEMPT; // Max attempts if no activity is detected
buffer[56,57] = PLM_LL_MAX_RPT_ATTEMPT; // Max repetition attempts (for processed ID)
buffer[58,59] = DEVICE_TIME_SYNC; // Timeclock update synchro frame interval
buffer[60,61] = CRC16;
3) Set module parameters: programming module parameters
uint8_t *buffer;
/* IF AES ENCRYPTION IS ENABLED */
buffer[0] = 36;
/* IF AES ENCRYPTION IS DISABLED */
buffer[0] = 20;
buffer[1] = APP_SERVICE_FRAME;
buffer[2,3] = target_module.group;
buffer[4,5,6,7] = target_module.address;
buffer[8] = SERVICE_PARAM_SET;
buffer[9] = PROG_GRP_DEVICE_DATA;
buffer[10,11] = new_group;
buffer[12,13,14,15] = new_address;
buffer[16] = (uint8_t)module_working_mode;
buffer[17] = hop_level;
/* IF AES ENCRYPTION IS ENABLED */
buffer[18 -> 33] = *AES_key_buffer; // AES Key 0 to 15, 16 bytes
buffer[34,35] = CRC16;
/* IF AES ENCRYPTION IS DISABLED */
buffer[18,19] = CRC16;
module_working_mode
-------------------------
b7 b6 b5 b4 b3 b2 b1 b0
-------------------------
| | | | | | | +-- 1 = Reserved
| | | | | | +----- 1 = ACK frame requested 0 = ACK frame not requested
| | | | | +-------- 1 = bACK frame requested 0 = bACK frame not requested
| | | | +----------- 1 = Dongle works also as a repetitor 0 = Dongle doesn't repead frames
| | | +-------------- 1 = Static repeater behaviour 0 = Repeat only frames with no
| | | response
| | +----------------- 1 = Grouping filter (subnet) enabled 0 = Grouping filter disabled
| +-------------------- 1 = Encrypted data 0 = Clear data
+----------------------- 1 = Reserved
