DocID023833 Rev 5 29/36
STM32F42xx and STM32F43xx Revision code on device marking
35
Appendix A Revision code on device marking
Figure 1, Figure 2, Figure 3, Figure 4 and Figure 5, Figure 6, Figure 7 show the marking
compositions for the TFBGA216, WLCSP143, LQFP208, UFBGA176, LQFP176, LQFP144
and LQFP100 packages, respectively.The only fields shown are the Additional field
containing the revision code and the Year and Week fields making up the date code.
Figure 1. TFBGA216 top package view
-36
7EEK9EAR
$ATECODE9EAR7EEK
!DDITIONALINFORMATIONFIELD
INCLUDING2EVISIONCODE
