8 | Connection STOBER
46
03/2020 | ID 442793.03
8.3.1.3 UL-compliant line fuses
For UL compliance, use one of the following protection measures:
§ Class CC, CF, J, T, G or RK1 safety fuses
§ Circuit breakers
More detailed specifications about the appropriate fuses can be found in the following table:
Size Type Safety fuse Circuit breakers
I
N
[A] U
N
[V
AC
]
0 SC6A062 15 600 Recommendation:
EATON
FAZ-B10/3-NA
Manufacturer No. 132723
Alternative:
EATON
FAZ-B15/3-NA
Manufacturer No. 132721
1 SC6A162 25 600 EATON
FAZ-B25/3-NA
Manufacturer No. 132726
1 SC6A261
Tab. 44: UL-compliant line fuses
Information
To ensure problem-free operation, always comply with the recommended trigger limits and trigger characteristics of the
fuse elements.
8.3.2 Residual current protective device
STOBER devices can be protected with a residual current protective device (RCD) to detect residual currents. Residual
current protective devices prevent electrical accidents, especially ground fault through the body. They are generally
classified by their triggering limit and suitability for detecting different types of residual currents.
Depending on the function, leakage currents may occur when operating drive controllers. Leakage currents are interpreted
as residual currents by residual current protective devices and may therefore lead to false triggering. Depending on the
relevant power supply connections, residual currents may occur with or without a DC current component. Because of this,
you should take into consideration both the magnitude as well as the profile of the possible leakage or residual current
when selecting a suitable RCD.
DANGER!
Electrical voltage! Risk of fatal injury due to electric shock!
This product can cause a direct current in the protective grounding conductor.
▪ If a residual current protective device (RCD) or residual current monitoring device (RCM) is used for protection in case
of direct or indirect contact, only one RCD or RCM of type B is permitted on the power supply side of this product.
