Storm Audio ISP CORE 16 - Specifications

40
Specifications
Audio
Audio Formats 16ch (9.1.6/11.1.4), 192 kHz
Dolby Atmos, DTS:X Pro,
IMAX Enhanced, Auro-3D
All Legacy codecs
StormXT*
Audio Inputs 4x RCA analog (7.1 or 2.0)
3x Coaxial SPDIF
3x Optical Toslink
Streaming ROON Ready
Post-Processed Outputs 16ch, 48 kHz
Audio outputs 16ch analog (XLR)
1x Optical Toslink for Zone2
(Downmix)
Bass Management Multiple subwoofers
Per channel crossover
Standard and Expert*
Multi-way speaker XO 6, 12, 18, 24, 36, 48 dB/
Octave, Linkwitz-Riley and
Butterworth
Equalization per Channel up to 20 band PEQ
REW plugin
Calibration Dirac Live with
Bass Control* module
* optional features, consult your reseller
HDMI
Inputs / Outputs 7 / 2, matrix*
Input Specs 7 ea. HDCP2.2 / HDMI2.0
Output Specs 2 ea. HDCP2.2 / HDMI2.0
ARC/eARC on HDMI Out1
On Screen Display
Max Resolution UHD, 4K 60fps 4:4:4 8bpc
18 Gpbs all ports
HDR HDR10, HLG & Dolby Vision
Deep Color Support 12bpc
CEC Limited to ARC support
* optional features, consult your reseller
Power Supply
Type Universal
Range 100 to 240V
Control
Control Modules Available Crestron & Crestron Home
Control4
RTI
Savant
ELAN
IR Front panel sensor
Rear panel I/O, jack 3.5mm
DC Trigger x4, jack 3.5mm, 12V DC
Software assignable to
inputs, presets, on/standby
or manual operation
Applications WebUI: Setup & remote
control
iOS App: remote control
Android App : remote
control
Network 100 Mbps Ethernet
Options
UMIK-1 Microphone USB microphone.
Allows for Monitoring,
Calibration and RTA
function.
Weight and Dimensions
(net product)
L x W x H (cm / inches)
with rack ears mounted
42 x 47.90 x 15.50
16.53 x 18.86 x 5.91
Weight 8.3 KG | 17.6 LBS
