Storm ST17145 - Installation Instructions; Indoor Unit Outline Dimensions

'XFWHGLQGRRUXQLWIRU0XOWLVSOLW5,QYHUWHU
5
ċ Installation Instructions
1 Outline Dimension Drawings of the Indoor Unit
Note: the unit in the followings figures is mm, unless otherwise specified.
Fig.1
Table 1: Outline Dimensions
˖
Item
Model
A
B
C
D
E
F
G
H
I
J

742
491
662
620
700
615
782
156
200
635


942
491
862
820
900
615
982
156
200
635
