STOVES 500DIT - Appliance Dimensions - DIS Models; DIS Twin Cavity Dimensions and Cutouts; DIS Single Cavity Dimensions and Cutouts

Oven Furniture
medium grill oven roasting cake
pan & trivet shelf dish tray
x 1 x 1x 1x 1
566 mm
596 mm
30 mm
* 520 mm
555 mm
Appliance Dimensions - DIS
516 mm
500 mm
130 mm
(550 mm)
A
E
H
506 mm
536 mm
30 mm
* 743 mm
495 mm
* Underside of side trim to underside of strut
Fig 9. 500 DIS Single Cavity Fig 10. 500DIS/T Twin cavitiy
Door dimensions
A 370 mm x 450 mm
B 225 mm x 450 mm
C 445 mm x 450 mm
D 145 mm x 450 mm
E 185 mm x 450 mm
F 335 mm x 450 mm
G 260 mm x 450 mm
H 185 mm x 450 mm
X 405 mm x 250 mm
Y 225 mm x 250 mm
Z 370 mm x 250 mm
(E & H, and G & H are Bifold door sizes)
516 mm
500 mm
130 mm
(754 mm)
A
B
816 mm
800 mm
130 mm
(754 mm)
A
B
Y
X
Z
566 mm
596 mm
30 mm
* 743 mm
555 mm
Fig 8. 500DIS - Single Cavity
Fig 7. 500 & 800 DIS Twin CavityFig 6. 800DIS Twin Cavity
Fig 5. 500DIS & DIS/T Twin cavities
08 24520 04 19
