Strata Media Application Server and Integrated Voice Mail Cards
Physical Specifications
84 Strata CIX General Description 04/13
Figure 21 MAS Rear Panel
MicroMAS
Figure 22 MicroMAS back panel
Table 20 MicroMAS Basic Specifications
Physical
Dimensions (W x H x D) 12.17” x 3.3” x 12.8” (309 x 84 x 325 mm)
Weight 15 lbs. (6.81 Kg)
Environmental
Conditions
Operating Temperature 32ºF~104ºF (0ºC~40ºC)
Storage Temperature -40
ºF~140ºF (-40ºC~60ºC)
Operating Humidity 10%~95% (non-condensing)
Electrical
Requirements
(AC Input)
System 1
115VAC, at 6 amps (50/60 Hz) – standard
230VAC at 3.5 amps (50/60 Hz)– switch
configured
Provide host system with 15A circuit breaker and dedicated circuit.
I
I
O
<
C
AC Input Power Switch
Reset
Switch
Power
AC Power
Connector
Switch
AC Power Cord
Connectore
220V and 110V Switch
Main Power
Switch
USB
RJ45 LAN
Connection
Mouse
Keyboard
Com 2
Com 1
VGA Connector
PCI Card Slots
Line-in (Blue)
Line-out (Green)
Mic-in (Pink)
003-MM
