Strata CIX200
Basic Specifications
20 Strata CIX General Description 04/13
Basic Specifications
The following table lists the parts and basic specifications of the CIX200 Rack Mount Cabinets.
Power Backup
An Uninterruptible Power Supply (UPS) is required for power backup on a CIX200. The UPS is
similar to the ones used for computer systems and networking equipment.
Dimensions of each
cabinet – Base
(CHSUB192A) and
Expansion (CHSUE192A)
Height: 2U or 3.5 inches (88.9 mm)
Width: 17.3 inches (440mm – without bracket);
19 inches (483 mm – with bracket)
Depth: 16.1 inches (410mm)
Weight: 16 lbs (7.2 kilograms)
Power Supply Unit (PSU) Initially Built-in
19" Rack Installation
Dimension
IEC297-1 (EIA RS 310-D)
465.1mm (front face screw pitch – width)
Installation
Rack-mount (preferred) or Table top.
Important! Do not place the equipment on the floor or in a dusty place.
